Description
A-B 1336-BDB-SP72D Gate Drive Module
Rockwell Automation’s 1336-BDB-SP72D gate drive module works specifically with 1336STE drives powering 480V/250HP motors. We’ve tested this module in actual production lines where it maintains consistent performance even under continuous heavy load conditions.
Technical Specifications
| Brand | Allen-Bradley |
| Model | 1336-BDB-SP72D |
| Series | 1336 FORCE |
| Operating Voltage | 480V AC |
| Output Frequency | 30 kHz |
| Dimensions | 5.75″ x 3.5″ x 1.25″ |
| Weight | 0.8 lbs |
This module works with 1336-SP72D drive systems commonly found in metalworking plants and material handling equipment. The SP72D variant specifically supports regenerative braking applications. We’ve successfully integrated these modules into existing systems for clients in the automotive and plastics industries.
Compatible with: 1336-SP72D drives, 1336STE motor controllers, and 1336-BAA-SP72D accessory modules. The field-installable design allows for quick replacement without system reconfiguration.
Our Service Advantage
We maintain over 200 Rockwell Automation modules in stock at our Guiyang warehouse. All units undergo 48-hour burn-in testing before shipment. Need urgent replacement? Message me on WhatsApp for real-time availability and pricing.
Our team has direct experience installing these modules in textile machinery and CNC machining centers. Email Yezi for application-specific advice or to request a product datasheet.
12-month warranty included • No restocking fees • Technical support available
