Description

ABB PM861AK01 controller module

Hardware configuration
Processor: It adopts the MPC860 processor, which can quickly and accurately handle various control algorithms and data processing tasks, meeting the demands of industrial automation and control systems.
Memory: Equipped with 16M RAM. The larger memory capacity helps enhance the data processing capability and operating speed of the controller, allowing multiple complex control programs to run simultaneously and handle a large amount of data.
Communication interface: Supports multiple interface types, such as Ethernet (RJ45 connector, supporting IEEE802.3 Ethernet standard, CAN be connected to Category 5 shielded twisted-pair cable or optical fiber), serial port, CAN bus and other interfaces, facilitating the connection of various devices and sensors, and achieving data interaction and communication with other systems.
Other components: This controller includes a PM861A CPU, a TP830 baseplate (with a width of 115mm), a TB850 CEX-bus terminal module, a TB807 module bus terminal module, a TB852 RCU-link terminal module, and a battery for memory backup (4943013 -) 6) And a 4-pin power plug (3BSC840088R4).

Product characteristics
Modular design: It supports modular design. Users can customize and expand it according to different application requirements, and choose different module combinations to adapt to various control scenarios, making the system configuration more flexible.
High reliability: Designed for long-term reliable operation in harsh industrial environments, it adopts high-quality electronic components and manufacturing processes, capable of stable operation in severe industrial conditions, featuring high reliability and stability.
Strong security: It has a complete security mechanism, such as user permission management and data encryption, which can effectively protect the security of the system and data, and prevent illegal access and data leakage.

Technical parameters
Power supply: 24 volts DC (voltage range: 19.2-30 volts DC).
Power consumption: Typical value 6.0 watts, maximum value 10.3 watts.
Relative humidity: 5% – 95%, no condensation.
Rated isolation voltage: 500 volts AC.
