Description

ABB PP836 Panel 800 series Function key panel

Display screen
Type: 6.5-inch TFT color display screen.
Resolution: 640×480 pixels.
Display area: 61×33 mm.
Backlight: White controllable backlight with adjustable contrast.
Input: 6 standard keys, 4 function keys (tactile surface buttons), supporting touch operation.

Power supply:
Option: Supports 12 V DC or 24 V AC/DC.
Allowable voltage range: 10.2 to 28.8 V DC or 20.4 to 26.4 V AC (47 to 63 Hz).
Power consumption: The typical value is 65 mA at 24 V DC, 40 mA at 12 V DC, and 90 mA at 24 V AC.
Communication interface: Supports Ethernet, RS-232, RS-485, etc.
Working environment
Temperature: 0℃ – 55℃.

Application scenarios: It is suitable for various industrial automation scenarios and can be used in conjunction with ABB’s various control systems, providing operators with a convenient human-machine interaction interface. It is widely applied in the automation control processes of industries such as chemical engineering, power, and metallurgy.
