Description

ABB  PP875  standard 7-inch touch screen

Product Overview: The Panel 800 series operation panel is user-friendly, intuitive and ergonomic. It is compact in size to save space and features a series of advanced functions. As one of them, the PP875 is designed to make process automation simple, featuring touchscreen operation and advanced functions for process and equipment control.

Display features: It adopts a TFT/LED display screen, presenting vivid colors with a resolution of 800×480 (16:9) and a brightness of 350cd/m². It can provide clear images and rich colors, and supports dimming function, allowing the screen brightness to be adjusted according to the ambient light. The touch screen is resistive touch and can achieve precise operation.
Performance parameters: The processor is ARM9 (1GHz), with 512MB of main memory and a 2GB solid-state drive. Among them, 1.5GB can be used for application storage, ensuring that the device can handle various tasks quickly and run applications smoothly.

Communication interface: Provide multiple communication interfaces It includes one 10/100Base-T Ethernet shielded RJ45 interface, one USB 2.0 interface (500mA), as well as one RS232 serial port, one RS422/485 serial port and one RS485 serial port (only when COM2 is RS485) It is convenient to connect and interact data with other devices and systems, and can be connected to controllers of multiple brands. It supports multiple connection options and is suitable for local communication, expansion, remote access, etc.

Appearance design: The shell is made of sturdy and lightweight die-cast powder-coated aluminum, and the front panel can withstand damp, dusty and harsh environments. The product dimensions are 204mm×143mm×50mm, with a net weight of 0.8kg. It is lightweight and takes up little space, making it easy to install and use.

Electrical characteristics: The power supply adopts + 24V DC (allowable range 18-32V DC), the operating temperature range is -10 ℃ to + 60℃, the maximum humidity is 85%, and it is suitable for various industrial environments.

Functional features:
Easy to use: Equipped with comprehensive and integrated templates and libraries, configured through the Panel Builder tool, which has a familiar Microsoft Windows environment and multi-language support, enabling fast, easy and efficient engineering design.
Advanced graphics: Vector-based high-resolution graphics, combined with icon-based interfaces, navigation and control, make operation intuitive and convenient.
Platform openness: Based on accompaniment. The open architecture and technical construction of the NET framework can connect controllers of multiple brands, providing convenience for system integration.
Simulation function: Applications can be directly simulated and run in Panel Builder 800, facilitating users to conduct tests and optimizations before use.
