Description

ABB  PP881  Panel 800 series touch screen

Display features: It adopts a TFT/LED display screen with brilliant colors, a resolution of 1024×600 pixels, a brightness of 500cd/m², and supports dimming function. The touch screen is resistive touch, enabling precise operation.
Performance parameters: The processor is ARM9 (1GHz), with 1GB of main memory and a 2GB solid-state drive. Among them, 1.5GB can be used for application storage, ensuring that the device can handle various tasks quickly and run applications smoothly.

Communication interface: Provide multiple communication interfaces It includes 2 10/100Base-T Ethernet shielded RJ45 interfaces, 2 USB 2.0 interfaces (500mA), as well as 1 RS232 serial port, 1 RS422/485 serial port and 1 RS485 serial port (only when COM2 is RS485) It is convenient to connect and interact data with other devices and systems at this time.

Electrical characteristics: The power supply adopts + 24V DC (allowable range 18-32V DC), and the power consumption is 21.6W.
Environmental characteristics: The operating temperature range is -10 ℃ to + 60℃, the relative operating humidity is 5% to 85% (non-condensing), the storage temperature is -20 ℃ to + 70℃, and it can withstand vibration and shock of 1g/15g respectively.

Functional features:
Easy to use: Equipped with comprehensive and integrated templates and libraries, configured through the Panel Builder tool, which has a familiar Microsoft Windows environment and multi-language support, enabling fast, easy and efficient engineering design.
Advanced graphics: Vector-based high-resolution graphics, combined with icon-based interfaces, navigation and control, make operation intuitive and convenient.
Platform openness: Based on accompaniment. The open architecture and technical construction of the NET framework can connect controllers of multiple brands, providing convenience for system integration.
Simulation function: Applications can be directly simulated and run in Panel Builder 800, facilitating users to conduct tests and optimizations before use.
