Description

ABB  PP886  standard 15-inch touch screen

Display features: It adopts TFT/LED display screen, with brilliant display colors, a brightness of 450cd/m², a display resolution of 1280×800 pixels, a ratio of 16:10, and supports dimming function. The touch screen is resistive touch, ensuring precise operation.
Performance parameters: The processor is ARM9 (1GHz), with 1GB of main memory and a 2GB solid-state drive. Among them, 1.5GB can be used for application storage, capable of quickly processing tasks and running applications.

Communication interface: It provides 2 10/100Base-T Ethernet shielded RJ45 interfaces, 2 USB 2.0 interfaces (500mA), as well as 1 RS232 serial port, 1 RS422/485 serial port and 1 RS485 serial port (only when COM2 is RS485 At this time, it is convenient to connect with other devices and systems and interact with data.
Appearance design: The shell is made of die-cast powder-coated aluminum, and the front panel can withstand damp, dusty and harsh environments.

Electrical characteristics: The power supply adopts + 24V DC (allowable range 18-32V DC), and the power consumption is 31.2W.
Environmental characteristics: The operating temperature range is -10 ℃ to + 60℃, the relative operating humidity is 5% to 85% (non-condensing), the storage temperature is -20 ℃ to + 70℃, and it can withstand vibration and shock of 1g/15g respectively.
Certification: Passed CE, FCC and KCC certifications, complies with UL 61010-2-201 standard, suitable for Marine use (DNV, KR, GL, LR, ABS, CCS), and also conforms to RoHS and WEEE directives.
