Description

BENTLY   330103-00-04-10-02-00    3300 XL Series 8mm eddy current proximity probe

Basic information:
Brand: Bently Nevada.
Model: 330103-00-04-10-02-00.
Origin: The United States.

Size specification:
Non-threaded length: “00” indicates 0 inches.
The total length of the shell: “04” represents 40mm.
Total length: “10” indicates 1.0 meter (3.3 feet).
Connection and cable: “02” indicates the use of a micro coaxial click loc™ connector and standard cable.
Product certification: “00” indicates no specific certification requirements.

Probe material:
Probe tip material: Polyphenylene sulfide (PPS), which has excellent wear resistance.
Probe housing material: AISI 303 or 304 stainless steel (SST), sturdy and durable, suitable for use in harsh environments.

Performance features: Operating based on the eddy current effect, it can measure the distance between the measured metal conductor and the probe surface non-contact, with high linearity and high resolution both statically and dynamically. It can accurately measure the static and dynamic relative displacement changes between the measured object and the probe end face. It has the advantages of good long-term working reliability, high sensitivity, strong anti-interference ability, fast response speed, and is not affected by oil, water and other media.

Application fields: Mainly applied in the vibration and position measurement of fluid lubrication bearing machines, as well as key phase reference and speed measurement. It is often used for long-term real-time monitoring of parameters such as shaft displacement, shaft vibration, and shaft speed of large rotating machinery. It can analyze the working condition and fault causes of the equipment, effectively protecting and pre-maintaining the equipment.
