Emerson  1C31113G01  Analog input module

Functions and Applications
Function Overview: It is mainly used to convert analog signals sent by external sensors and other devices into digital signals for processing and analysis by the control system, playing a key role in data acquisition in industrial automation systems.
Application fields: Widely applied in industrial automation, energy management, environmental monitoring and other fields. In industrial automation scenarios, temperature sensors, pressure sensors, etc. can be connected to achieve monitoring and control of various parameters in the production process. In the field of energy management, it can be used for parameter collection and monitoring of energy equipment in industries such as power, petroleum and natural gas. In the environmental monitoring system, environmental parameter data can be collected and processed, such as data on air quality, water quality, etc.

Main characteristics
Input range: The input range is ±20mV, with high sensitivity. It is suitable for scenarios that require precise measurement of minute signal changes, such as some experimental equipment with high precision requirements or parameter monitoring in precise production processes.
Resolution: With a 13-bit resolution, it can precisely convert analog signals into digital signals, providing relatively fine signal conversion results. This helps accurately reflect the minute changes in sensor measurements and offers a reliable data foundation for subsequent control and analysis.

Composition structure: It is usually composed of analog input circuits, analog-to-digital converters (ADC), filters and interface circuits. The analog input circuit is responsible for receiving external analog signals. ADC converts analog signals into digital signals; Filters are used to remove noise and interference from signals to ensure the quality of the signals. The interface circuit realizes data communication and connection with the control system or other devices.
Communication capability: Supports data communication via RS-485 bus, provides analog-to-485 conversion function, facilitates data exchange with control systems or other devices with RS-485 interface, and facilitates system integration and expansion.
