Description

EMERSON  1C31113G06  High-precision analog input module

Technical parameters
Electrical characteristics
Number of input channels: Usually 8 channels (capable of simultaneously collecting 8 analog signals).
Input signal type:
Voltage signal: ±10V, ±5V, ±1V, ±0.5V, ±0.1V, etc. (configurable).
Current signal: 4-20mA, 0-20mA, etc. (configurable).
Resistance signal: Supports thermal resistors (RTD), such as PT100, PT1000, etc.

Resolution: 24 bits (providing extremely high-precision signal conversion).
Sampling rate: Up to 100Hz per channel (configurable).
Accuracy: ±0.01% (typical value, depending on the range and environmental conditions).
Input impedance:
Voltage input: ≥10MΩ.
Current input: ≤250Ω.

Environmental parameters
Operating temperature: -40°C to + 70°C (industrial grade standard, suitable for harsh environments).
Storage temperature: -40°C to + 85°C.
Humidity: 0-95% RH (no condensation).
Anti-vibration: Complies with the IEC 60068-2-6 standard (10-58Hz, 1g).
Impact resistance: Complies with the IEC 60068-2-27 standard (11ms, 15g).

Power supply requirements
Supply voltage: 24VDC (±10%).
Power consumption: ≤5W (typical value).
Power isolation: The isolation between channels is ≥500Vrms, providing electrical isolation protection.
