Description

Emerson  1C31132G01  Ovation series module

Function and application: It is an analog output module, mainly used to route the field signals in the electronic module to the terminal block. Through digital-to-analog conversion, it converts the input digital signals into controllable continuous current and signals, and outputs them to external devices.

Performance characteristics:
Multiple module execution rates: Supports various execution rates such as 25ms, 50ms, 100ms, 500ms, 1s, 2s, 5s, 10s, 30s, and 60s, allowing for selection based on actual application requirements.
Communication function: Supports communication protocols such as Modbus TCP (server and client), Ethernet/IP (client: Category 1 and Category 3), and OPC UA server, facilitating data interaction and integration with other devices or systems.
Strong adaptability to working environment: The working temperature range is -40° C to 60°C (-40°F to 140°F), and the storage temperature range is -40° C to 85°C (-40°F to 185°F). The relative humidity is 5% to 95%, and it is non-condensing. The protection grade is IP20, NEMA 12, and it can adapt to various industrial environments.
Other features: It has six built-in Ethernet ports, which can save cabinet space; Supporting 1:1 redundancy, there is no need to increase occupied space or change configuration, which improves the reliability of the system.

Other features: Equipped with an LCD display screen, it can show error codes, valve positions, equipment temperatures, calibration modes and other information, making it easier to set, debug and troubleshoot. It has the function of monitoring the position of limit switches; There are also backup auxiliary inputs that can be used to monitor any dry contact switches in the HART 7 network.
