Emerson  1C31169G02  Serial Link controller module

Overview
This module is a high-performance serial link controller designed for Emerson Ovation control systems, providing a universal and reliable solution for connecting multiple serial devices in various industrial applications.

Functional characteristics
The communication protocol support is extensive: It supports multiple serial communication protocols such as RS-232, RS-485 and Modbus, which can adapt to the communication requirements of different devices.
High data transmission rate: The maximum data transmission rate can reach 115.2kbps, enabling rapid data transmission and interaction.
Multi-serial port support: It has two serial ports and can simultaneously connect to multiple serial devices.
The parameter software is configurable: Communication parameters can be configured through the software, allowing users to flexibly set them according to actual application scenarios.
Clear status indication: Each serial port is equipped with an LED indicator light, which can visually display the working status of the port, facilitating fault detection and system monitoring.

Technical Specification
Communication protocols: RS-232, RS-485, Modbus.
Data transmission rate: Up to 115.2kbps.
Number of serial ports: 2.

Application field
Connect the remote I/O module: Achieve the connection between the Ovation process control system and the remote I/O module to expand the input and output capabilities of the system.
Connect to other PLC and DCS systems: The Ovation system can be connected to programmable logic controllers (PLCS) or distributed control systems (DCS) of other brands to achieve data interaction and collaborative work among different systems.
Connect HMI devices: Connect to the human-machine interface (HMI) device to provide operators with an intuitive system monitoring and operation interface.
Connect to serial devices such as printers: It can be connected to devices such as printers to achieve data printing output or other related functions.
