Description

Emerson  1C31179G02  digital control system module

Technical parameters
Analog input channels: 8.
Input range: -10VDC to + 10VDC, -5VDC to + 5VDC, 0-5VDC, 0-10VDC, 0-20mA, 4-20mA.
Resolution: 16 bits.
Sampling rate: 50 samples per second per channel.
Input impedance: 1 megohm.
Accuracy: +/-0.1% of full scale.
Linearity: +/-0.05% of full scale.
Common-mode rejection Ratio (CMRR) : 120dB.
Isolation: 1500Vrms between the channel and the ground.
Power consumption: Maximum 5W.
Operating temperature: -40°C to + 70°C.
Storage temperature: -40°C to + 85°C.
Humidity: 5%-95% RH, non-condensing.

Application scenarios
This module is typically used in industries such as oil and gas, chemical engineering, power generation, steel, cement, and papermaking, as well as in other fields that require precise control and monitoring of industrial processes. It provides reliable analog input data acquisition and processing functions for the automation systems of these industries, helping to optimize and manage the production process.
