Description

Emerson  1C31194G01  Digital input module

Electrical specification
Input signal type: Receive digital signals for detecting the status of external devices, such as the on and off of switches, the engagement of relays, etc.
Input channels: It has 16 channels and can simultaneously connect to 16 different digital signal sources.
Input voltage range: It varies depending on the electronic module selected. The 1C31107G01 electronic module supports 24/48V AC/DC input, while the 1C31107G02 electronic module supports 125V AC/DC input.
Logic level: The specific level threshold is determined by the input voltage range and the module design.

Environmental specification
Operating temperature: -40℃ to + 85℃.
Storage temperature: Usually between -55 ℃ and + 125℃.
Humidity: It can operate normally in an environment of 5% to 95% without condensation.

Functional characteristics
Channel isolation: Each input channel has an electrical isolation function, which can prevent electrical interference between channels and improve the stability and reliability of the system.
Fault detection: It is equipped with a fuse blow detection function, which can monitor the status of the auxiliary power supply. When the fuse blows or the auxiliary power supply voltage drops below the minimum value, it will send a attention status signal to the Ovation controller.
Input type selection: By choosing different personalized modules, the input can be configured as differential input or single-ended input. The 1C31194G01 personalized module is used for single-ended input configuration, while the 1C31110G02 personalized module is used for differential input configuration.
