Description

Emerson  1C31234G01  Digital I/O module

Working power supply
Supply voltage: 24VDC (±10%)
Power consumption: ≤7W (typical value), ≤10W (maximum value)
Input parameters
Input type: Dry contact or wet contact (24VDC)
Number of channels: 8 digital input channels
Logic level: High level ≥15VDC (logic 1), low level ≤5VDC (logic 0)
Isolation voltage: 2500V AC (Isolation between channels and from the system)

Output parameters
Output type: Relay output (SPDT, single-pole double-throw)
Number of channels: 8 digital output channels
Contact capacity: 250VAC/30VDC, 5A (resistive load)
Contact life: ≥ 100,000 times (under full load)
Response time
Input response: ≤5ms (including filtering)
Output response: ≤10ms (relay engagement), ≤5ms (release)
