Working Principle: The Ovation controller operates based on a real-time operating system, adhering to the POSIX1003.1b open system standard, and supports multitasking and preemptive task scheduling. It collects data from on-site sensors through input/output (I/O) modules and stores the data in a point database. Then, according to preset control strategies such as continuous (PID) control and Boolean logic, it processes and calculates the collected data. The calculation results are output through the I/O modules to control on-site actuators, thereby realizing the control of industrial processes. Meanwhile, it is equipped with a sequence of events processing function with a resolution of 1 millisecond, which can record key events in real-time.

Functional Features
Powerful Control Capability: It can execute simple or complex regulatory and sequential control strategies, realize functions such as continuous (PID) control, Boolean logic, advanced control, special logic, and timing functions. It can also perform data collection, process point alarm handling, etc., and can handle up to 16,000 points.
Flexible I/O Interfaces: It supports various I/O types, including 8, 16, and 32-channel analog and digital I/O modules. It can also connect to special I/O modules such as mechanical health monitoring modules and generator excitation modules, which can meet the needs of different industrial scenarios.
Easy Integration: Based on open industrial standards, using the Ovation distributed global database, third-party products can be easily integrated. PLC can also become a direct site of the Ovation data highway.
High Reliability: The controller’s hardware architecture is designed with a redundancy mechanism to ensure that the system can maintain continuous control and monitoring tasks in case of a single hardware failure. It also has a safe shutdown function, which can safely shut down the system when key power plant equipment fails.
Convenient Maintenance: It uses standard Ovation engineering tools for configuration and maintenance, which can reduce maintenance costs and difficulties.

Technical Parameters
Power Requirements: Dual redundant power terminals, rated input voltage is 24VDC, and the power supply range is 19.2-30VDC.
Dimensions and Weight: The dimensions are approximately 20.09cm (width) × 21.59cm (height) × 18.97cm (depth), and the weight is about 0.14kg.
Operating Temperature: The operating temperature range is -20℃ to +70℃.
Network Communication: It supports various communication network protocols such as Modbus, Profibus, Foundation Fieldbus, etc., and can communicate with other devices through industrial Ethernet.

Specific Application Cases:

Gas Turbine Control: Emerson applied the integrated solution of the Ovation expert control system to the Shenzhen Nantian GT13E2 combined cycle unit. After the transformation, each functional group of the gas turbine and steam turbine, as well as APS, were put into operation smoothly. The gas turbine and steam turbine were ignited successfully at one time, the unit was connected to the grid and operated stably, and the entire transformation project was completed ahead of schedule during the overhaul period.
Small Hydropower Station Control: The Ovation compact controller can be used in small hydropower stations as an independent controller connected to Ovation remote stations, I/O modules, or third-party I/O, to realize the control of hydropower station equipment, such as monitoring the operating status of water turbines and adjusting valve openings, ensuring the stable operation of the hydropower station.
Photovoltaic Power Station Control: In photovoltaic power stations, it can monitor inverter efficiency and control the charging and discharging strategies of energy storage devices. By collecting relevant data and conducting analysis and processing according to preset logic, it realizes the optimization of energy management in photovoltaic power stations and improves energy utilization efficiency.
Water Treatment System Control: This module is optimized for the water/wastewater treatment industry. It can be used to monitor and control various parameters in the water treatment process, such as water quality indicators, water level, and flow rate. By controlling equipment such as water pumps and valves, it realizes the automatic operation of the water treatment system, ensuring that the water quality meets the standards and the system operates stably.
Microgrid Control: It can be applied in microgrids to coordinately control distributed power sources, energy storage devices, and loads in the microgrid, ensuring that the microgrid can supply power stably whether it is operating in an island mode or connected to the main grid. It optimizes energy distribution and improves the reliability and operating efficiency of the microgrid.
