Emerson  5X00070G05  thermocouple temperature module

Input characteristics
Input type: Supports multiple thermocouple types, such as K-type, J-type, T-type, E-type, etc., which can adapt to application scenarios with different temperature measurement ranges and accuracy requirements.
Measurement range: It varies depending on the type of thermocouple connected. Take the common K-type thermocouple as an example, the measurement range is usually from -200 ℃ to 1372℃.

Measurement accuracy: Generally, it can reach ±0.1% of reading + 1℃, ensuring the accuracy of temperature measurement.
Cold end compensation accuracy: Usually up to ±0.5℃, effectively compensating for the influence of environmental temperature changes on the measurement results and enhancing the reliability of the measurement.

Channel configuration
Number of channels: It usually has multiple input channels and can simultaneously connect multiple thermocouples for multi-point temperature measurement. It is applicable to systems that need to monitor temperatures at multiple locations.
Channel isolation: Each channel is isolated from one another. The isolation voltage is generally no less than 500Vrms to prevent signal interference between channels and ensure the independence and accuracy of the measurement.

Electrical characteristics
Working voltage: Usually DC 24V, allowing a certain voltage fluctuation range, such as ±10%, to adapt to different power supply conditions.
Power consumption: Generally, it ranges from a few watts to tens of watts. The specific power consumption depends on the number of channels of the module and its working status.

Communication interface
Communication protocol: Supports standard protocols for communication with the Ovation control system or other compatible systems, such as Modbus, Profibus-DP, etc., facilitating data interaction and system integration with the upper computer or other devices.
Data transmission rate: The data transmission rate is relatively high, generally reaching tens of Kbps to several Mbps.

Environmental adaptability
Operating temperature range: -40 ℃ to + 70℃.
Humidity range: It can operate normally in a humidity environment of 0-95% without condensation.
