Description

Emerson  5X00106G02  16-channel analog input module

Input characteristics
Number of channels: 16 channels.
Input type: Analog quantity.
Input range: -40mA to + 40mA, supports HART protocol, and is compatible with various HART intelligent transmitters.
Accuracy: ±0.1% of full scale.
Resolution: 16 bits.
Noise: Less than 0.1μV p-p.
Response time: less than 250ms.
Power supply characteristics: 24V DC, power consumption 20W.
Environmental characteristics
Operating temperature: -40℃ to + 70℃.
Humidity: 0% to 95% relative humidity (no condensation).

In terms of data processing, this module can accurately collect and process various analog signals in industrial processes, convert them into digital signals and then transmit them to the control system for analysis and processing. For instance, in industrial fields such as water treatment, petrochemicals, and power, analog signals like pressure, temperature, and flow can be collected to provide accurate data support for system control and decision-making.
