Description

GE  DS200EXPSG1A  extended power module

Basic information
Belonging series: GE Mark VIe Control System
Function and purpose: To provide redundant power support for the I/O modules and other components in the control system
Product positioning: Critical power supply guarantee equipment, ensuring the continuous operation of the system during power fluctuations or failures

Technical parameters
Input voltage: 120/230V AC, 50/60Hz (automatic adaptation)
Output voltage: 24V DC (Regulated output, fluctuation ≤±5%)
Maximum output power: 150W (continuous output)
Efficiency ≥90% (under typical load conditions)
Startup time ≤500ms (cold start)
The steady-state response time is ≤100ms (when the load changes by ±50%)
Ripple and noise ≤100 MVP-P (within a 20MHz bandwidth)
Operating temperature: -40°C to + 70°C (For derating use: derating by 1.5% for every 1°C increase above 60°C)
Storage temperature: -55°C to + 85°C
Humidity: 5% – 95% (no condensation)
Vibration: 5-500Hz, 2G (conforming to IEC 60068-2-6 standard)
Impact 50G, 11ms (in compliance with IEC 60068-2-27 standard)
