Description

GE  DS200SHVIG1BHD  Mark V series thyristor high-voltage interface board

Performance Introduction:
Signal processing capability: It can receive voltage signals as low as -500mV and as high as 500mV, convert all input signals into differential frequency signals ranging from 0 to 500kHz, and then send the converted signals to the integrated power card of the driver to achieve signal conversion and transmission, thereby meeting the communication requirements among various parts of the system.

Configurability: The board is equipped with 17 user-configurable patch cords, each of which contains a 10:1 current transformer, providing additional attenuation capacity. Users can flexibly configure them according to specific application scenarios and system requirements, enhancing the board’s adaptability to different working conditions.

Status indication and protection: It is equipped with 3 on-board LED indicator lights to indicate abnormal conditions such as filter fuses, facilitating users to promptly identify faults and carry out troubleshooting. Meanwhile, the circuit board integrates standard voltage-limiting hardware components such as capacitors, resistors, diodes and application-specific integrated circuits, which can suppress and limit voltage, protect the circuit board and the system from damage caused by excessive voltage, and improve the stability and reliability of the system.

Technical parameters:
Signal processing parameters
Input voltage range: -500mV to 500mV.
Output frequency range: Convert the input voltage signal into a differential frequency signal ranging from 0 to 500kHz.

Hardware configuration parameters
Patch cord configuration: There are 17 user-configurable patch cords on the board. Each patch cord contains a 10:1 current transformer, which can provide additional attenuation capacity.
Indicator lights: There are 3 on-board LED indicator lights, which are used to indicate abnormal conditions such as filter fuse.

Product specification parameters
Manufacturer: General Electric (GE).
Product series: Mark V
Component Number: DS200SHVIG1BHD.
Product type: Thyristor high-voltage interface board.
