Description

GE  IC200ACC001  Versamax series PLC battery module

Functional characteristics
Provide backup power supply: When the main power supply fails or there is a power outage, provide power support for the real-time clock and some key data storage circuits in the PLC system to ensure that the real-time clock can still operate during the power outage period, and save important configuration information, program data, and some key intermediate data being processed, etc., to prevent data loss. Ensure that the system can quickly and accurately return to the operating state before the power outage after the power supply is restored.
Maintain real-time clock accuracy: Supply power to the real-time clock circuit of the PLC to ensure the accuracy of the real-time clock. Take the IC200CPU001 as an example. The battery backup real-time clock accuracy it is equipped with is 100ppm (i.e. 0.01%) or ±9 seconds per day, which can ensure the accuracy of the system’s time-based operation and logical scheduling. It is suitable for internal timer and counter instructions, as well as other functions that have requirements for time accuracy.

Application field
Papermaking and printing industry In the automatic control systems of paper machines, printing machines and other equipment, IC200ACC001 ensures that the PLC can save key information such as the operation parameters and production tasks of the equipment when there is an unexpected power outage, so as to quickly resume production after the power supply is restored, guarantee the quality of paper production and the accuracy of printing, and reduce production delays and material waste caused by power outages.
Textile printing and dyeing industry: In the control of textile machinery and printing and dyeing equipment, it is combined with PLC to achieve precise control of the production process. IC200ACC001 protects relevant data when power is cut off, enabling the equipment to continue production as originally planned after power is restored, ensuring the quality of textiles and the accuracy of printed patterns, and avoiding production chaos and defective products caused by data loss.

CNC machinery: In CNC machining centers, lathes, milling machines and other equipment, the operation status of the equipment is monitored and controlled in conjunction with PLC. IC200ACC001 ensures that relevant configurations and data are not lost in the event of a power failure, guaranteeing that the equipment can accurately return to the state before the power failure when powered on again, maintaining the accuracy and continuity of processing.
Metallurgical industry: It is used in the control systems of metallurgical equipment such as blast furnaces, converters, and continuous casting machines. In these harsh environments with high temperatures and high dust levels, the IC200ACC001 provides a stable backup power supply for the PLC, ensuring that the equipment’s automatic control process is not affected by power outages, guaranteeing the safety and stability of the production process, and avoiding production accidents and quality issues caused by data loss.
