GE IC687BEM731CA-AB Bus Controller Input/Output Module

• Input Voltage: 24V DC.
• Communication Protocol: Modbus RTU.
• Operating Temperature Range: -40℃ to 70℃.
• Dimensions: 118mm x 30mm x 129mm.
• Input/Output Channels: Supports 16 inputs and 16 outputs, totaling 32 channels.
• Protection Class: IP20.
• Input Types: Dry contacts, photoelectric switches.
• Output Type: Relay.
• Output Current: 2A.

• High Reliability: Manufactured with advanced electronic components to ensure long-term stable operation.
• High Channel Density: Provides 32 I/O channels, which can reduce the number of modules and save space.
• Easy Installation and Configuration: The module is designed simply for easy installation and maintenance.
• Support for Multiple Communication Protocols: Supports protocols such as Modbus RTU, facilitating integration with other devices.

• The module receives signals from external sensors (such as limit switches, photoelectric sensors, temperature transmitters, etc.) through 16 input channels.
• The input types support dry contacts (such as switch signals) or photoelectric signals, converting physical signals into digital signals (high/low level).

• The internal circuit filters and isolates the collected signals (opto-isolation or relay isolation) to enhance anti-interference ability.
• The processed signals are stored in the module’s registers, waiting for the main controller to read.

• The module communicates with the main controller (such as PLC, DCS) through the Genius bus protocol (or compatible Modbus RTU protocol).
• The main controller polls the module periodically to read the input status and issue output commands.

• The main controller sends control commands (such as switching on/off of equipment) to the module through the bus.
• After receiving the command, the module drives external actuators (such as solenoid valves, contactors, indicator lights, etc.) through 16 relay output channels (each channel with a maximum current of 2A).

• The module monitors its own status in real-time (such as power failure, communication interruption, output overload) and feeds back to the main controller through LED indicators or status registers.
• The relay output supports a fail-safe mode (such as maintaining a specific state when power is off).
