Description

GE  IC693ACC335  digital servo shaft terminal board

Function and Application
Servo system interface
As a bridge between digital servo modules (such as DSM302) and servo amplifiers (such as GE Fanuc α/β series), it realizes bidirectional signal transmission.
Supports position, speed and torque control, and is suitable for scenarios that require high-precision motion control (such as robots, CNC machine tools, and automated production lines).

I/O expansion
It provides 18 screw terminals for connecting external devices (such as limit switches, encoders, sensors) to expand the input/output capacity of the system.
Support the conditioning and transmission of digital input/output signals to enhance system flexibility.
Fault diagnosis and protection
The operating status of the servo system is monitored in real time through indicator lights and status feedback.
Support fault detection such as overload and over-range to ensure the safe operation of the system.

Application scenarios
Industrial robots: Control the joint movement of mechanical arms to achieve precise positioning and trajectory planning.
CNC machine tools: Drive the spindle and feed axis, supporting high-speed cutting and precision machining.
Automated production line: Synchronously controls multi-axis movement to achieve tasks such as material handling and packaging.
Printing and packaging equipment: Precisely control the speed and position of the rollers to ensure printing quality.
