Description

GE  IC693ALG390  analog output module

Functions and Characteristics
Dual-channel analog output
It supports 2 independent analog output channels, capable of simultaneously outputting voltage or current signals to meet the requirements of multi-device collaborative control.
Output type and range:
Voltage output: -10V to +10V, 0V to +10V (optional).
Current output: 4mA ~ 20mA, 0mA ~ 20mA (optional).

High precision and stability
12-bit resolution: The voltage resolution is 4μV/LSB and the current resolution is 4μA/LSB, ensuring the fineness of the signal output.
Accuracy: ±0.1% full scale, suitable for scenarios with high control accuracy requirements (such as precision control valves, servo motor control).
Fast update rate: 5ms output update cycle, meeting real-time control requirements.

Electrical isolation and anti-interference design
1500VDC built-in isolation: Electrical isolation between channels and between channels and the system, effectively resisting electromagnetic interference (EMI) and common-mode voltage surges in industrial environments, ensuring signal stability.

Wide temperature operating range:
Operating temperature: -40°C to 70°C Storage temperature: -40°C to 85°C, suitable for harsh industrial environments (such as high-temperature workshops and outdoor equipment).
Flexible configuration and convenient maintenance
Plug and Play: Supports hot plugging (subject to system configuration permission), facilitating quick on-site replacement or expansion.
LED status indicator light: It displays in real time the status of module power supply and channel faults (such as overload, short circuit), etc., simplifying fault detection.
Modular design: Compatible with the Series 90-30 PLC rack, output parameters can be flexibly configured through programming software (such as VersaPro).
