Description

GE VMIVME-5565-110000 high-performance VMEbus reflective memory node card

Interface type: It adopts the VMEbus interface, which complies with the VMEbus standard, facilitating connection and communication with various devices that conform to the VME standard.
Memory capacity: It is usually configurable as 128MB SDRAM. Some sources also mention that 128MB or 256MB SDRAM can be optionally equipped, which can meet the requirements of different applications for data storage capacity.
Network transmission rate: The transmission rate ranges from 43MB/s to 170MB/s, depending on the size of the data packet, enabling high-speed data transmission.

Node quantity: Supports up to 256 nodes, capable of connecting multiple independent systems to build large-scale distributed systems.
Optical fiber distance: When using multimode optical fiber, it can reach 300 meters, and if single-mode optical fiber is adopted, it can reach 10 kilometers, providing greater flexibility for system layout.
Data packet size: The dynamic data packet size ranges from 4 bytes to 64 bytes and can be adjusted according to actual application requirements to optimize data transmission efficiency.
Optical fiber type: Supports multimode optical fiber. Multimode optical fiber has a large core diameter, is easy to couple, and is suitable for short-distance high-speed data transmission.

Size: Conforms to the standard size of VMEbus 6U Eurocard, facilitating installation in a standard VME chassis and forming a system together with other VME modules.
Features: It has the characteristics of high speed, low latency and deterministic transmission, which can ensure the rapid and accurate transmission of data between multiple independent systems. At the same time, it supports transparent data transmission and interrupt functions, facilitating the design and development of the system.

This product is suitable for application scenarios with extremely high requirements for data transmission speed and synchronization, such as flight simulators and data acquisition systems in the aerospace field, process control and robot control in industrial automation, high-speed data acquisition and distributed test systems in the test and measurement field, as well as military simulation and command and control systems in the defense field.
