Description

HIMA  F7130A  power supply module

Basic information:
Product type: Power module.
Manufacturer: HIMA.
Product Number: F7130A.
Country of origin: Germany.

Technical Specification:
Input voltage: 24V DC, allowable range from -15% to + 20%, ripple less than 15%.
Output voltage: Provide 5V DC for the central equipment/IO module, with an accuracy of ±0.25V/10A; Provide 5V DC for Hibus with an accuracy of ±0.25V/1A.
Power conversion: It belongs to a DC/DC converter and has electrical isolation function, with an efficiency of no less than 70%.
Protection functions: It is equipped with overvoltage protection and current limiting functions, and the output circuit can prevent short circuits.
Indicator light: The front panel is equipped with an LED indicator light, which is used to indicate the status of the input voltage (L+) and output voltage.

Other features:
Module size: 4SU (standard unit).
Operating temperature range: No specific restrictions are clearly specified. It is speculated that it can operate stably within the general industrial environmental temperature range.
Application scenarios: Mainly provide stable DC power supply for devices such as programmable logic controllers (PLCS) in industrial automation systems like HIMA’s Pes H41q system, and are applicable to fields such as machine tools, robots, process control, building automation, medical equipment, and transportation systems.
