Description

HONEYWELL  FC-PSU-UNI2450U-V1.0  High-performance Power Module

Main features:
High efficiency: Adopting advanced switching mode design, the efficiency is over 87% when inputting 230V AC, which can reduce heat generation and extend the equipment’s service life.
High stability: The output voltage is stable, with low ripple and noise, less than 40mVpp, providing reliable power for the equipment.
High safety: Built-in overvoltage, overcurrent, and overload protection functions ensure the safe operation of the equipment.
Wide voltage input: The input voltage range is 110-240V AC (operating range 93-253V AC), suitable for different regional power grids.
Compact design: Dimensions are 420.5mm × 140mm × 90mm (width × height × depth), suitable for installation in limited spaces.

Technical parameters:
Input frequency: 47-63Hz.
No-load power consumption: 13W.
Output voltage: 25V DC or 28V DC.
Output current: 48A at 25V DC (-5°C to + 50°C), 43A at 28V DC (-5°C to + 50°C).
Isolation voltage: Input to output is 3750Vrms (1 minute).
Operating temperature: -5°C to + 70°C.
Storage temperature: -25°C to + 85°C.

Connectors: AC input is IEC 60320 C20 type socket (16A); DC output is 2 Phoenix PCV6-16/2-G1F-10, 16, with locking screws; alarm contacts are 3-pole Phoenix MC 1,5/3-G-3,81 socket.
Alarm function: Equipped with under-voltage alarm contacts. When the output voltage is lower than 22V DC, the relay will power off.
Function: Mainly provides stable DC power for various devices in industrial automation and control systems, ensuring the normal operation of the system.
Applications: Widely used in manufacturing automation production lines, power system monitoring in the energy industry, process control in the chemical industry, traffic control in the transportation field, etc. It can also be used in building automation systems to supply power to lighting control, security systems, and HVAC systems, etc.
