MOTOROLA  MVME162-013  high-performance industrial control module

Processor performance: Based on the enhanced 32-bit microprocessor MC68040, the main frequency can be selected as 25MHz or 32MHz. It is equipped with an 8KB cache, memory management unit (MMU), and floating-point operation unit (FPU), capable of efficiently handling complex algorithms and real-time tasks.
Memory and storage: Standard 4MB shared DRAM, expandable to 16MB, some models can be increased to 64MB by expanding the mezzanine. It also has 512KB of SRAM with a spare battery to ensure that data is not lost in case of power failure. It is equipped with 1MB of built-in Flash memory, supports EPROM and Flash expansion, and has a JEDEC standard 32-pin PLCC EPROM socket for convenient storage of system firmware and user programs.

Interface type: It is equipped with 4 serial communication ports, including the EIA-422/485 standard interface. One of the dual-wire RS485 ports can connect 32 8 series IEDs in a Daisy chain together. It also has 4 MVIP IndustryPack interfaces, allowing for flexible configuration of functions such as I/O. In addition, optional SCSI bus interface or local area network Ethernet transceiver interface are available to meet the connection requirements of different devices.
Bus features: Compatible with the VME bus standard, supports A32/D64 master/slave interfaces, has four levels of requesters, seven levels of interrupters and interrupt handling programs, and can add functional modules through expansion slots, with strong expandability.

Timer configuration: It features multiple programmable timers, including 4 32-bit programmable timers and a programmable watchdog timer, which helps with the system’s timing control and fault monitoring.
Environmental adaptability: The operating temperature range is -40 °C to + 85°C, the relative humidity is 5% to 95% (without condensation), and the seismic performance complies with the MIL-STD-810 standard. It can operate stably in harsh industrial environments.
Power supply requirements: Support wide-range DC input of + 5V and ±12V, with a typical power consumption of 24W, meeting the power supply requirements of distributed control architectures.

Application scenario: It can be applied in the power system and serve as the core controller of the substation automation system. It can also be used in the field of transportation, such as high-speed rail signal control systems; It can also be applied in fields such as military equipment and aerospace, responsible for tasks like data collection and real-time computing.
