Description

MOTOROLA  MVME162-530A  single-board computer module

Processor: It adopts the MC68040 enhanced 32-bit microprocessor, with a selectable main frequency of 25MHz or 32MHz. This processor is equipped with 8KB cache, MMU (Memory Management Unit) and FPU (Floating-point Unit), and is capable of quickly handling complex algorithms and real-time tasks.
Memory: Standard 4MB shared DRAM, supports expansion up to 16MB, and some models can be increased to 64MB by expanding the mezzanine. It is also equipped with a 512KB SRAM with a spare battery, which can protect critical data in case of power failure.

Storage: Built-in 1MB Flash memory, some models have 2MB, supports EPROM and Flash expansion, can store on-board monitors, debuggers or user-installed firmware.
Communication interface: It provides 4 serial communication ports, including EIA-232 and EIA-422/485 standards, supporting multiple communication protocols, and can be used to connect serial port devices to achieve serial data transmission.

Expansion capability:
VMEbus Interface: Compatible with the VMEbus standard, it supports A32/D64 master/slave interfaces, featuring four levels of requesters, seven levels of interrupters and interrupt handling programs. It can be connected to other VME devices, facilitating system function expansion and upgrade.

IndustryPack Interface: It provides 4 IndustryPack interfaces, which can be connected to various IndustryPack modules to expand functions such as I/O control, analog and digital signal processing, and meet the needs of different application scenarios.
Environmental adaptability: The operating temperature range is -40 °C to + 85°C, the relative humidity is 5% to 95% (without condensation), and the seismic performance complies with the MIL-STD-810 standard. It can adapt to harsh industrial environments and ensure stable operation in various complex industrial sites.
