NI  PXIE-5654  RF analog signal generator

Wide frequency coverage: With a frequency range of 250kHz to 20GHz, it can meet the signal generation requirements in various RF application scenarios, such as radar testing and satellite communication fields.
Low phase noise: At a 10GHz carrier and a 1kHz offset, the phase noise can reach -143dBc /Hz, providing stable and pure signal output. This is crucial for high-precision RF testing and can reduce signal interference and measurement errors.

Fast frequency tuning: The frequency tuning speed is fast, with a 10MHz frequency step of less than 10µs. It can quickly switch between different frequencies, improving test efficiency and is suitable for test scenarios that require frequent frequency changes.
High output power: The typical output power value can reach + 27dBm, and the RF output power range is up to 130dB, which can meet the requirements of high-power testing, such as receiver blocking testing, and also help overcome the signal attenuation problem within long cables.

Rich modulation functions: Supports multiple modulation methods such as amplitude modulation (AM), frequency modulation (FM), phase modulation (PM), and pulse modulation, capable of generating various types of signals to meet different testing and simulation requirements.
Compact modular design: Adopting the PXI compact modular form factor, it can be combined with other PXI module instruments, facilitating integration into the automated test system, saving space, and suitable for system construction in various application scenarios such as radar, RF ICs, and automotive testing.

Application fields: It is suitable for scenarios such as blocking testing/receiver desensitization, high-performance intermodulation distortion measurement, etc. It is mainly used in RFIC characterization, satellite testing, radar applications and other fields, and can also be used in various electronic warfare applications.
