NI  PXIE-8840  quad-core embedded controller

Processor and Performance: It adopts the Intel Core i7-5700EQ quad-core processor, based on the Broadwell architecture and 14nm process. The base frequency is 2.6GHz and the maximum Turbo frequency can reach 3.4GHz, which is dynamically adjusted through Intel Turbo Boost Technology 2.0. Equipped with a 6MB Intel Smart Cache, it can improve the data access speed.
Memory and storage: The standard configuration is 4GB single-channel 1600MHz DDR3L RAM, and it can be expanded up to 8GB at most, which can meet the processing requirements of large amounts of data. It also integrates a hard disk drive to provide stable storage space.

Rich interfaces: It has two 10/100/1000BASE-TX gigabit Ethernet ports, supporting high-speed data transmission. It also includes two USB 3.0 ports and four USB 2.0 ports, facilitating the connection of various peripherals. In addition, it is equipped with a serial port and other peripheral I/O, allowing for flexible configuration and connection to external devices.
Bus communication capability: It has the ability to communicate with the PXIe bus and computers, supports parallel processing of multiple controllers, and can be extended to distributed systems.

Real-time data processing: Supports real-time operating systems to ensure real-time control and data acquisition capabilities, suitable for application scenarios that require high-precision time synchronization and data processing. Even if the host is interrupted or restarted, the inserted LabVIEW real-time application will continue to run.
Compatibility and ease of use: Compatible with NI’s hardware and software. For example, it can run using the NI-DAQMX driver software. It can be used in conjunction with software packages such as LabVIEW, LabWindows/CVI or Measurement Studio, facilitating integration and expansion of existing systems, and providing easy-to-use software and graphical interfaces. It is convenient for users to quickly develop and debug applications.
