NI  SCXI-1180  circuit module

Hardware structure: Equipped with a front panel and a 50-pin ribbon cable assembly, it facilitates signal management and connection. It can be used in conjunction with the SCXI-1302 terminal block to achieve signal splitting.

Functional features: It can extend the signal lines that do not require conditioning from the rear to the front of the SCXI chassis, and also guide the I/O signals of a single data acquisition (DAQ) instrument to the front of the SCXI system, facilitating user access and operation of the signals. Furthermore, when used in conjunction with SCXI-1340, SCXI-1341 or SCXI-1342 cable assemblies, it can act as a Daisy chain extender to access the signals on the cables between the module and the plug-in board, especially the signals that the module is not in use.

Compatibility: Compatible with various data acquisition boards such as PC, AT and MC, and can be used in conjunction with NI-DAQ software (applicable to DOS, Windows, Lab Windows systems). It is also applicable to the NB series data acquisition boards and can collaborate seamlessly with LabVIEW or the NI-DAQ software for Macintosh.

Application scenarios: It is suitable for various scenarios such as data acquisition, signal measurement and control, and can be connected to analog sensors, signal generators, signal conditioning modules and other devices.

Advantages and features: The compact system design based on the SCXI chassis enables it to withstand harsh environmental conditions and has high durability and reliability. Meanwhile, the design of this module is convenient for integration with other devices or systems, which is conducive to system upgrade and expansion.
