NI  SCXI-1326  High-voltage terminal module

Basic features: It is a module with screw terminals, featuring 48 screw terminals, divided into 8 groups, with 6 terminals in each group. Each group contains one VCC, one GND and four channels. The specific uses of these terminals depend on the module they are connected to.
Electrical parameters: The maximum voltage is 300V, which belongs to CAT II type. It has 300Vrms common-mode isolation and can effectively ensure electrical safety and signal stability.

Function and application: Designed for high-voltage digital input or digital output applications, it is also highly suitable for temperature or voltage applications with a large number of channels. It can be connected to the front connectors of modules such as SCXI-1162, SCXI-1162 HV, SCXI-1163 and SCXI-1163 R to realize the access and transmission of signals.
Signal connection: As a shielded terminal module, it facilitates quick and easy signal connection. It also supports various signal types such as voltage, current, temperature and pressure, featuring high precision and low noise. It provides multiple connection methods such as screw terminals and DB-15 connectors, facilitating users to connect and manage signals.

Operating temperature: The recommended operating temperature range is 0℃ to 50℃, and the storage temperature range is -20 ℃ to 70℃. It can operate stably under certain temperature conditions.

Application fields: Widely used in industrial control, scientific experiments, sensor measurement, medical diagnosis and other fields. It can be used to drive motors, control experimental instruments, collect sensor signals, connect medical equipment signals, etc. It is widely applied in scenarios such as power electronics and motor drive where there is a demand for high-voltage signal processing.
