TRICONEX  3101  main processor module

Basic Information

• Brand and Manufacturer: TRICONEX, currently a brand under Schneider Electric.
• Type: Main Processor Module.
• Series Affiliation: Triconex Series.

Technical Parameters

• Processor: Adopts a dual-core PowerPC 32-bit processor running at 50MHz.
• Memory:
  • 6MB Flash PROM for storing application programs.
  • 16MB DRAM for control applications, programs, and SOE (Sequence of Events) data.
  • 8KB NVRAM for maintaining variables.
• Communication Interfaces: Supports multiple communication protocols, including Ethernet, RS-232, and RS-485.
• Operating Voltage: 24V DC.
• Temperature Range: -40°C to 70°C.
• Humidity Requirement: 5%–95% (non-condensing).
• Safety Certification: Complies with SIL 3 safety standards.
• Dimensions: 150mm×150mm×50mm.
• I/O Channels:
  • Typically 8 digital input channels supporting various input types and modes (e.g., dry contacts, optoelectronic, analog).
  • 8 digital output channels.

Key Features

• High Reliability: Utilizes Triple Modular Redundancy (TMR) design, with three independent processor channels operating in parallel. Through a majority voting mechanism, the system continues to function even if partial modules fail, effectively avoiding system downtime caused by single-point failures and ensuring high availability in critical applications.
• Strong Real-time Processing Capability: Supports high-speed, real-time data processing and decision-making, enabling rapid response to various events in industrial processes and timely execution of control logic to meet the needs of scenarios requiring high real-time performance.
• High Safety: Complies with SIL 3 safety standards, equipped with comprehensive fault detection and self-diagnosis functions. It monitors hardware status (e.g., processor, memory, communication links) in real time and feedbacks fault information via indicator lights or system logs to ensure safe and stable system operation.
• Good Scalability: Supports multiple I/O modules and communication protocols, seamlessly collaborating with other Triconex series modules (such as digital/analog I/O modules and communication modules). This allows flexible expansion of system scale and addition of functions based on actual requirements.

Application Areas

• Oil and Gas Industry: Used for control of refining and chemical production processes, natural gas transportation and storage, etc. It monitors process parameters and implements functions such as safety interlocks and emergency shutdowns.
• Power Industry: Suitable for power system control and protection, such as equipment status monitoring and protection in power plants and substations.
• Other Industries: Applied in steel, pulp and paper, water and wastewater treatment, chemical, pharmaceutical, and other industries, providing reliable safety control guarantees for their production processes.
