TRICONEX  DO2401  High-performance digital output module

TRICONEX DO2401

Basic Information

• Brand & Manufacturer: Manufactured by Invensys Triconex.
• Module Type: Digital Output Module.

Key Features

• Redundancy Design: Adopts a triple redundancy (TMR) architecture, ensuring the system can still operate normally if a single channel fails, which significantly enhances system reliability and stability.
• High Performance: Supports high-speed data processing and real-time response, enabling fast and accurate conversion of digital signals from the safety system into signals to drive field devices, meeting the real-time control requirements of industrial sites.
• User-Friendliness: Provides an intuitive user interface and simple configuration procedures, facilitating setup and management for operators and reducing the difficulty of use.
• Modular Design: Convenient for system configuration and maintenance. Users can flexibly install, disassemble, and replace modules according to actual needs, which also benefits system expansion and upgrading.

Technical Parameters

• Input Voltage: 24V DC.
• Output Current: Maximum 2A per channel.
• Number of Channels: Supports multiple channels, commonly configured with 16 or 32 channels.
• Operating Temperature Range: Typically -25°C to +70°C; some models support -40°C to +70°C.
• Storage Temperature Range: -40°C to +85°C.
• Humidity Range: 5% to 95% (non-condensing).
• Communication Interface: Supports communication protocols such as Modbus TCP/IP for data transmission and interaction with other devices.
• Safety Certification: Complies with SIL 2 certification standards, ensuring reliable safety performance.
• Dimensions: Approximately 100mm×50mm×20mm, compact in size and space-saving.
• Protection Level: Reaches IP65, with good dust and water resistance, suitable for harsh industrial environments.

Functions and Applications

Main Functions

• Signal Conversion and Transmission: Receives digital signals from the central processing unit, converts them into forms suitable for driving field devices, and transmits them to corresponding field devices to ensure accurate delivery of control commands.
• Precise Control Implementation: Precisely controls the operating status of field devices based on received digital signals, such as opening/closing valves, starting/stopping motors, etc., to meet the precise operation requirements of various devices in industrial production processes.
• System Safety Assurance: With its triple redundancy (TMR) technology and other designs, it ensures the system continues to operate normally in case of failures, effectively preventing safety accidents caused by equipment malfunctions or signal anomalies, and ensuring the safe and stable operation of industrial processes. Meanwhile, it has fault detection and diagnosis functions, which can promptly identify its own faults and issue alarms, facilitating timely handling by maintenance personnel and further improving system safety and reliability.

Specific Applications

• Oil and Gas Industry: Used for safety control in oil and gas storage, refining, and transportation. For example, in the liquid level control of oil and gas storage tanks, the DO2401 module controls related valves based on signals from liquid level sensors to achieve stable liquid level control; in refining units, it is used for emergency shutdown systems to quickly stop equipment in case of abnormal conditions, ensuring production safety.
• Chemical Industry: Applicable for safety monitoring in the storage and processing of hazardous chemicals. For instance, in chemical warehouses, it works with fire and gas detection systems to promptly drive fire-fighting equipment, close related valves, etc., when fire or gas leakage is detected, preventing accidents from expanding; in chemical production processes, it controls the inlet and outlet valves of reaction kettles to ensure the stable and safe production process.
• Power Industry: Applied to safety control in power plants and substations. For example, in power plants, it controls the emergency shutdown of steam turbines, quickly issuing shutdown commands to protect equipment safety when abnormalities such as excessive vibration, high temperature, or low lubricating oil pressure occur; in substations, it controls the opening and closing of switches to achieve reasonable dispatching of the power system and fault handling.
• Pharmaceutical Industry: Used for safety control in pharmaceutical production processes. In the clean workshops of drug production, it controls the operation of air conditioning systems to ensure indicators such as temperature, humidity, and cleanliness meet requirements; in production links such as drug synthesis and filling, it controls the operation of related equipment to ensure the accuracy and safety of the production process and drug quality.
• Transportation Industry: Applicable to emergency shutdown systems (ESD), fire and gas detection systems, etc. For example, in the loading and unloading equipment of large ports, an emergency shutdown system is set up to quickly stop equipment operation through the DO2401 module when situations such as personnel safety threats or equipment failures occur; in traffic facilities such as tunnels, it coordinates with fire and gas detection equipment to promptly detect and handle fire and harmful gas leakage.
• Nuclear Energy Industry: Used in nuclear reactor safety systems to monitor various parameters of the nuclear reactor and control related safety equipment as needed, such as the lifting of control rods and the start/stop of cooling systems, ensuring the safe operation of the nuclear reactor and preventing serious accidents like nuclear leakage.
