The ABB CI862K01 with part number 3BUA000037R1 is a rack-mounted field bus communication module for ABB AC 800M controllers under System 800xA DCS, dedicated for TRIO and Genius distributed I/O network interconnection. Unlike serial CI853K01 and S100-bus CI856K01, it integrates triple physical connectors: one 4-pin Phoenix terminal port for TRIO bus, paired with male and female DB9 ports for Genius loop networking, supporting dual-protocol switching via Control Builder M software. It draws 24V DC power from the AC800M CEX backplane bus, with typical operating current of 190mA and rated power consumption of 4.56W, equipped with built-in overvoltage, reverse connection and electrostatic discharge protection circuits. It delivers 700V DC galvanic isolation between controller backplane and field I/O bus, isolating ground potential differences to eliminate bus crash risks in multi-cabinet distributed layouts. It allows maximum 4 CI862 modules deployed on a single CEX bus, and each module supports up to 1000 distributed TRIO I/O points for large-scale field signal collection. Standard physical parameters match AC800M rack standards: dimensions 185mm × 59mm × 135mm, net weight 0.7kg, occupying two standard rack slots. Three front-panel LED indicators separately indicate backplane power supply, CEX bus link and field bus data transmission for on-site fault diagnosis without upper configuration software. It meets IEC 61000-6-2 industrial EMC standards, passing 20g shock and 150m/s² vibration testing. The operating temperature range is 5°C to 55°C, storage temperature -40°C to 70°C, with 5%-95% non-condensing humidity tolerance and IP20 indoor protection. It supports hot swapping when CPU load is below 40% without interrupting control logic. Manufactured in Sweden with CE certification, this classic lifecycle module is widely used for expansion and retrofitting of TRIO/Genius legacy I/O networks in power, pulp and chemical industries.
