Description

Bently  3500/92  communication gateway module

Extensive communication capabilities: Supports Ethernet TCP/IP and serial (RS232/RS422/RS485) communication, enabling the integration of all monitoring values and status of the 3500 series racks with process control and other automation systems.
Support for multiple communication protocols: Supports the Modicon Modbus protocol (via serial communication), Modbus/TCP protocol (a serial Modbus variant for TCP/IP Ethernet communication), and the proprietary Bently Nevada protocol (for communicating with 3500 rack configurations and data acquisition software packages). It can easily achieve seamless integration with other devices.

Configurable Modbus register function: With the configurable Modbus register function, users can flexibly configure registers according to their needs to achieve precise control and management of data, replacing the original primary value Modbus register function of 3500/90.

High-speed data acquisition and processing: Utilizing a high-speed internal network to collect information from other modules in the rack, including current measurement values with timestamps, module status, and current alarm status, etc. It features powerful data processing and storage capabilities, capable of handling various complex data and algorithms.
Flexible Ethernet connection: The Ethernet connection is in a 10BASE-T star configuration, using an RJ45 connector, supporting fast data exchange, and conforming to the IEEE802.3 standard.

This module is mainly applied in industrial fields such as petroleum, thermal power, nuclear power, new energy, wind power, shipping, transportation, power, and steel. It is suitable for scenarios where the 3500 series mechanical monitoring system needs to be integrated with other automation systems to achieve remote monitoring, control, and management of large-scale mechanical equipment.
