Description

G60: Product series, integrated protection device dedicated to medium and large synchronous generators

G03

G: High-performance new-generation CPU hardware equipped with dual fiber Ethernet ports and RJ45 electrical port

03: Full-function premium software license with built-in PMU synchrophasor measurement, complete IEC 61850 protocols and advanced waveform recording & diagnosis

HCH

H: 19-inch standard horizontal rack mounting

C: Standard monochrome LCD operation panel (not high-definition enhanced color panel)

H: Wide-range redundant DC power supply of 125/250 VDC

F8L: Premium CT/VT acquisition unit with 4 phase CT channels and 4 PT voltage channels, equipped with high-precision enhanced fault diagnosis

H6C: Basic hard contact outputs with 6 programmable trip contacts and online trip circuit supervision

M8N: High-performance extended CT module with 8 additional CT channels and advanced fault diagnosis algorithm

P6C: Primary communication module with 6 channels, dual Ethernet plus isolated RS485, supporting IEC 61850, GOOSE and PRP dual-network redundancy

U6C: Secondary redundant communication module with 6-channel dual Ethernet architecture for hot standby backup of substation-wide network

W6C: Extended control output module with 6 programmable control outputs featuring real-time circuit supervision
