Description

GE  VMICPCI-7806  single-board computer

Processor Based on the Pentium M processor series, there are multiple frequencies available such as 1.1GHz, 1.6GHz and 1.8GHz. The enhanced Pentium M processor has a 1M-byte L2 cache, while Celeron M has a 512KB L2 cache, which can provide powerful computing capabilities. Meet the processing requirements of complex tasks and data-intensive processes.
Memory: Accepts a 200-pin SODIMM DDR module, supporting memory configurations of 256MB, 512MB and 1GB, and can be expanded up to 1.5GB DDR SDRAM at most, providing sufficient memory space for system operation.

Interface:
Ethernet interface: Equipped with two Ethernet controllers, it supports 10/100/1000BaseTX interfaces, providing high-speed and stable network connections, facilitating data communication and interaction between the device and other systems.
Serial interface: Two high-performance 16550-compatible serial ports, which can be used to connect various serial devices, such as modems, sensors, etc., to achieve serial data transmission.
USB interface: Supports USB 2.0, facilitating the connection of external devices such as mice, keyboards, storage devices, etc., to expand the functions of the system.
Other interfaces: It features serial ATA support, provides a 64-bit / 66MHz CompactPCI® bus interface, fully supports PICMG®2.16, and also comes with a PMC expansion site for front panel access, allowing connection to various standard-compliant expansion cards to further expand system functionality. In addition, it also integrates functions such as video and Ultra ATA/100 IDE support.

Electrical and environmental parameters:
Working voltage: 24V DC.
Ambient temperature: 0°C to 60°C.
Environmental humidity: 5% to 95%, non-condensing.

Functional features:
Adopting Intel’s new highly integrated small Footprint 6300esb I/O controller hub, it provides dual PMC sites (64-bit / 66 MHZ PCI-X and 32-bit / 33 MHZ PCI), suitable for I/ O-intensive applications.
It features IPMI support, enabling remote management and monitoring functions, and facilitating the maintenance and management of the equipment.
It can run many of today’s embedded operating systems, such as VxWorks, QNX and Linux, etc., and has good compatibility and flexibility.

Application fields: It is applicable to multiple industries such as aerospace, national defense, automobiles, telecommunications, industrial automation, simulation, instrumentation, process control and monitoring, factory automation, automated testing systems, and data acquisition systems, providing high-performance computing and control capabilities for equipment in these fields.
