HIMA F3423 Digital Output Module

• Multi-channel Output: Equipped with 8 isolated relay output channels, which can independently control 8 different devices, suitable for industrial scenarios requiring multiple output controls.
• High Current Driving: Each channel can output a maximum current of 2A, capable of driving relatively high-power equipment such as contactors and solenoid valves.
• Easy Installation: Adopts a standard DIN rail mounting method, facilitating installation in industrial control cabinets, saving space and ensuring firm installation.
• Wide Voltage Range: The operating voltage range is 18-30VDC, which can adapt to various power supply environments, enhancing the flexibility of the module’s application.

• Input Voltage: 24VDC.
• Total Output Current: Maximum 12A.
• Operating Temperature Range: -25℃ to +60℃, enabling stable operation in relatively harsh industrial environments.
• Communication Protocol: Supports Modbus RTU protocol, facilitating communication and data interaction with other devices that comply with this protocol.
• Dimensions: Approximately 120mm × 50mm × 30mm, with a compact size, easy to integrate into existing control systems.
• Weight: Approximately 0.2kg, light in weight, without imposing excessive burden on the mounting bracket.

• High Safety Performance: Complies with international safety standards such as IEC 61508, supports SIL 3 safety integrity level, and has passed relevant certifications. It can ensure reliable operation in safety-critical applications and is applicable to industries with extremely high safety requirements such as chemical and oil & gas industries.
• Strong Load Capacity: Each channel can output a maximum current of 2A, capable of driving a variety of devices, meeting the needs of various loads in complex control systems, such as solenoid valves and small motors.
• Fast Response: With a switching frequency of up to 10kHz and a switching speed of less than 1ms, it can quickly respond to control signals and timely execute output actions in dynamic industrial processes, which is crucial for equipment requiring rapid start-stop control.
• Wide Operating Temperature Range: The operating temperature range is -20℃ to +70℃, and some data shows it can be as low as -25℃, enabling stable operation in various harsh industrial environments, whether in high-temperature steel plants or low-temperature outdoor oil & gas facilities.
• Good Voltage Adaptability: Supports a wide operating voltage range, usually 18-30VDC, and some modules are compatible with 48/60VDC and 60VAC power supplies, which can flexibly adapt to different power supply systems, enhancing the module’s applicability in different industrial scenarios.
• High Insulation Protection: Has high insulation capability, which can effectively prevent dangers such as electric shock, ensuring personnel safety. It is particularly suitable for places such as chemical processing or manufacturing factories where electrical hazards exist.
• Compact and Lightweight: With a small size, compact structure, and light weight, it can be easily integrated into existing control cabinets, saving space, especially suitable for application environments with limited space.
• Redundant Design: Supports redundant configuration, improving the fault tolerance of the system. When a certain channel fails, other channels can continue to work normally, ensuring the continuity and stability of the system.
• Integrated Diagnostic Function: Built-in diagnostic function can monitor the module status in real-time, helping to quickly identify and eliminate faults, improving system availability and maintenance efficiency, and reducing downtime.
• Strong Compatibility: Compatible with HIMA’s Hi Quad, Himatrix and other series of products, it can be easily integrated into existing safety systems, facilitating system expansion and upgrading, and protecting users’ initial investment.
