Honeywell   CC-TCNT01   C300 controller input/output terminal assembly

Main Functions

• Providing Wiring Terminals: Offers reliable and convenient wiring terminals for connecting field sensors, actuators, and other automation devices to the control system, enabling signal input and output.
• Simplifying System Installation and Maintenance: Its design streamlines installation, maintenance, and troubleshooting. Clear terminal identification and user-friendly wiring methods allow engineers to complete connections quickly, reduce errors, and help maintenance personnel locate and resolve faults, thereby lowering overall system integration and operation costs.
• Ensuring Stable Signal Transmission: Adopts high-quality terminal design to ensure connection reliability and stability even in harsh industrial environments with vibrations, guaranteeing stable signal transmission.
• Supporting Flexible Expansion: Can be used in conjunction with various I/O modules of Honeywell’s ControlEdge™ PLC series, supporting termination of analog, digital, and special function modules, providing users with flexible I/O expansion capabilities to meet diverse application scenarios.

Technical Parameters

• Terminal Type: Screw terminals.
• Wiring Capacity: Accepts wires from AWG 28 to 12 (0.08 to 3.3mm²).
• Number of I/O Channels: Depends on the connected I/O module.
• Supported Signal Types: Supports analog, digital, and special function module signals.
• Isolation: Depends on the connected I/O module.
• Operating Temperature: -40°C to +70°C.
• Storage Temperature: -40°C to +85°C.
• Relative Humidity: 5% to 95% (non-condensing).
• Mounting Method: DIN rail mounting.

Product Features

• Seamless Integration: Specifically designed for Honeywell C300 controllers and ControlEdge™ PLC series I/O modules, ensuring electrical and signal compatibility to achieve optimal system performance.
• Robust and Durable: Constructed with industrial-grade materials and design, adaptable to wide temperature ranges, high humidity, and other industrial environments, enabling long-term reliable operation under harsh conditions.

Application Fields

• Oil and Gas Industry: With complex production processes, this industry requires real-time monitoring and precise control of various parameters. CC-TCNT01 can connect field instruments such as pressure transmitters, temperature sensors, flowmeters, and valves, transmitting signals detected by these instruments to the control system for effective monitoring and control of the production process, ensuring safe and stable operations.
• Chemical Industry: Chemical production involves numerous chemical reactions and material transportation processes, demanding high-level automation control. CC-TCNT01 can connect sensors, actuators, analytical instruments, and other devices of reaction kettles, helping build a complete automation control system to achieve precise control of parameters such as reaction temperature, pressure, and material flow, ensuring efficient and stable chemical production while enhancing product quality and production safety.
• Power Industry: The operation of power plants requires automation control of various equipment and processes to ensure reliable and efficient power generation. CC-TCNT01 can connect sensors, switches, control valves, and other devices in power plants to C300 controllers, enabling condition monitoring and control of power generation equipment, such as temperature and pressure control of boilers and speed regulation of steam turbines, to ensure stable power production.
• Water Treatment Industry: The water treatment process includes multiple links such as water source intake, water purification, and sewage discharge, requiring monitoring and control of parameters like water level, flow, and water quality. CC-TCNT01 can connect water level sensors, flowmeters, pumps, valves, and other devices to achieve automated management of the water treatment process, automatically adjusting equipment operation based on changes in water quality and quantity to ensure effluent quality meets standards.
• Manufacturing Industry: In manufacturing, automated production lines and robot control systems are increasingly adopted to improve production efficiency and product quality. CC-TCNT01 can connect sensors, actuators, encoders, and other devices on production lines, transmitting various production process information to the control system while receiving control system commands to operate equipment, enabling precise control and automated operation of production lines.
• Pharmaceutical Industry: Drug production has strict requirements for environmental and process control, ensuring every link meets quality standards. CC-TCNT01 can connect various process parameter sensors, control valves, and other devices to achieve precise control and real-time monitoring of parameters such as temperature, humidity, pressure, and material ratio in the drug production process, guaranteeing the quality and safety of drug production.
• Food and Beverage Industry: The production process of this industry needs to ensure food hygiene and quality while improving production efficiency. CC-TCNT01 can connect sensors, actuators, and other production equipment to achieve automated production and quality control. For example, in food processing, it precisely controls parameters such as temperature, time, and material flow to ensure food taste and quality, while reducing manual intervention and improving production safety and stability.
