MOTOROLA  MVME167-33B  single-board computer

Processor: It adopts the MC68040 microprocessor with a main frequency of 33MHz.
Memory: Supports 32-bit DRAM of 4/8/16/32/64MB with parity check protection. Alternatively, DRAM of 4/8/16/32/64/128/256MB is available, featuring ECC (Error Check and Correction) protection. In addition, it is equipped with 128KB SRAM and battery backup is optional.

Bus and Interface: It is equipped with dual independent 64-bit PCI buses, with a bus speed of up to 66MHz and a PMC station. It provides a gigabit Ethernet interface, an additional 10/100BASE-TX Ethernet interface and two serial ports. It includes a 64-bit PCI expansion mezzanine connector that can connect up to four additional PMCS. Its Universe II VME interface and PMCspan connector are compatible with the dedicated PCI extension mezzanine connector and are isolated from the PMC site on the dedicated 33MHz PCI bus segment, allowing both PMC sites to operate at 66MHz.

I/O interface: It provides 5V, 24V and analog I/O for PLC use. There is an incremental orthogonal encoder input on each axis for encoder/analog mode. It has 13-bit analog output and can be controlled by PLC or used as a digital servo regulation monitor. It is controlled by on-board local logic and features high-speed digital output (four each of 24V and 5V).

Data transmission mode: The VME bus transmission mode can be D16, D16/BLT, D32, D32/BLT or D64/BLT. It supports non-aligned data transmission and has error correction capability and self-diagnosis capability.
Others: The input voltage range is 89-280VAC.
