MOTOROLA  MVME167PA-36SE  digital control board card

Electrical parameters: Rated voltage is 120Vac, output voltage range is 85 to 132Vac, frequency is 50/60Hz.
Output channels: Each module has 16 outputs, divided into two groups, with eight outputs in each group.
Isolation performance: The isolation from the field to the backplane (optical) and the rack ground is 250Vac continuous and 1500Vac for 1 minute, and the isolation from group to group is 250Vac continuous and 1500Vac for 1 minute.

Output current: At 60°C, the maximum output current at each point is 0.5 amperes, and the maximum output current for each group is 3 amperes.
Output characteristics: The maximum inrush current for one cycle is 20 amperes, the minimum load current is 50mA, the maximum output voltage drop is 1.5 volts, and the maximum output leakage current at 120Vac is 2mA. The maximum connection response time is 1ms, and the maximum shutdown response time is half a cycle.
Power consumption: When all outputs are connected, the power consumption from the 5Vdc bus on the backplane is 315mA.
Fuse: Equipped with 2 3-ampere backplate fuses, part number 44A724627-111.

In addition, this module can be installed in any I/O slot of the RX3i system, supports hot plugging, and is usually equipped with a separately numbered LED to indicate the on/off status of points 1 to 32. It may also be equipped with the MC68040 33MHz CPU, have 64MB of memory, and be equipped with E-net, SCSI interfaces, etc.
